Wood fiber insulation boards

Bulk density: 200 kg/m³
Thickness: 35 mm
Beltermo standart dimensions: 2480*580 mm
Edge: tongue and groove, straight
Max. length\min. length: 2850/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external insulation of the roofing and heat insulation of outer walls under protective covering.
Internal insulation of flooring before jointless floors screed (laminate, parquet paneling) is possible.

How to install boards:
- boards should be placed closely to each other without gaps;
- a dry, even and technically perfect surface should be provided, boards should be protected from moisture for longer use;
- it's forbidden to step over the boards between rafters;
- boards are not bearing structures (for example, in case of snow load)

Bulk density: 180 kg/m³
Thickness: 60 mm
Beltermo standart dimensions: 1875*575 mm
Edge: tongue and groove, straight
Max. length\min. length: 2850/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external insulation of the roofing and heat insulation of outer walls under protective covering.
Internal insulation of flooring before jointless floors screed (laminate, parquet paneling), insulation of outer walls and internal walls under facade lining are possible.

How to install boards:
- boards should be placed closely to each other without gaps;
- a dry, even and technically perfect surface should be provided, boards should be protected from moisture for longer use;
- boards should be placed at right angle against rafters;
- it's forbidden to step over the boards between rafters;

Bulk density: 180 kg/m³
Thickness: 80 mm
Beltermo standart dimensions: 1875*575 mm
Edge: tongue and groove, straight
Max. length\min. length: 2850/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external insulation of the roofing and heat insulation of outer walls under protective covering.
Internal insulation of flooring before jointless floors screed (laminate, parquet paneling), insulation of outer walls and internal walls under facade lining are possible.

How to install boards:
- boards should be placed closely to each other without gaps;
- a dry, even and technically perfect surface should be provided, boards should be protected from moisture for longer use;
- boards should be placed at right angle against rafters;
- it's forbidden to step over the boards between rafters;

Bulk density: 180 kg/m³
Thickness: 100 mm
Beltermo standart dimensions: 1875*575 mm
Edge: tongue and groove, straight
Max. length\min. length: 2850/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external insulation of the roofing and heat insulation of outer walls under protective covering.
Internal insulation of flooring before jointless floors screed (laminate, parquet paneling), insulation of outer walls and internal walls under facade lining are possible.

How to install boards:
- boards should be placed closely to each other without gaps;
- a dry, even and technically perfect surface should be provided, boards should be protected from moisture for longer use;
- boards should be placed at right angle against rafters;
- it's forbidden to step over the boards between rafters;

Bulk density: 140 kg/m³
Thickness: 60 mm
Beltermo standart dimensions: 1875*575 mm
Edge: tongue and groove, straight
Max. length\min. length: 2850/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external insulation of the roofing, insulation of garret floor on an even surface.
Can be used as external insulation under the lining of ventilated facades, isolation of outer walls and floor.

How to install boards:
- boards should be placed on a dry, even and solid surface;
- boards should be placed closely to each other without gaps;
- it's forbidden to step over the boards between rafters;
- boards are not bearing structures (for example, in case of snow load).

Bulk density: 140 kg/m³
Thickness: 80 mm
Beltermo standart dimensions: 1875*575 mm
Edge: tongue and groove, straight
Max. length\min. length: 2850/800 mm


Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external insulation of the roofing, insulation of garret floor on an even surface.
Can be used as external insulation under the lining of ventilated facades, isolation of outer walls and floor.

How to install boards:
- boards should be placed on a dry, even and solid surface;
- boards should be placed closely to each other without gaps;
- it's forbidden to step over the boards between rafters;
- boards are not bearing structures (for example, in case of snow load).

Bulk density: 110 kg/m³
Thickness: 60 mm
Beltermo standart dimensions: 1200*600 mm
Edge: straight, step
Max. length\min. length: 1250/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external and internal insulation of the roofing and external heat insulation of outer walls under protective covering. Internal insulation of outer walls and structures of frame and frame-panel houses is possible.

How to install boards:
- boards should be stored and placed under dry conditions;
- boards should be placed closely to each other without gaps;
- boards should be placed on the roofing with Beltermo Top or Beltermo Ultra.
- boards should be placed with Beltermo Multi in case of external insulation of outer walls.

Bulk density: 110 kg/m³
Thickness: 100 mm
Beltermo standart dimensions: 1200*600 mm
Edge: straight, step
Max. length\min. length: 1250/800 mm

Composition:
- natural fibers from coniferous wood
- polyurethane-based resin MDI (4%)
- paraffin wag emulsion (1,5%)

Description and area of use:
Damp-proof boards.
Recommended for external and internal insulation of the roofing and external heat insulation of outer walls under protective covering.
Internal insulation of outer walls and structures of frame and frame-panel houses is possible.

How to install boards:
- boards should be stored and placed under dry conditions;
- boards should be placed closely to each other without gaps;
- boards should be placed on the roofing with Beltermo Top or Beltermo Ultra.
- boards should be placed with Beltermo Multi in case of external insulation of outer walls.
